Automation and industrial processes in the leisure sector
Fadilec, an engineering firm and integrator of global solutions, operates in the leisure sector.
To be as close as possible to our customers, we have two branches – one in
Laudun in the
Gard region (30) and one in
Vénissieux near
Lyon in the
Rhône region (69).
Our multidisciplinary teams design, manufacture and install complete automated systems.
Some of our projects in the leisure sector
Fadilec teams perform interventions in the areas of:
- Manufacture of composites
- Manufacture of skis and bindings
- Press loading in plastics processing.
Project duration: 5 months – 900 hours
Spotlight on a monitoring machine with vison and marking; VB supervision and axis management:
Rotary transfer control and lapping of bindings (26 stations)
∴ Task
- Study and realisation of the electrical installation
- Study and development of the Schneider PLC program
- Development of supervision in Visual Basic
- Development of a video acquisition application with image analysis in VB
∴ Resources
Over a period of 5 months:
- Project Manager
- Electrical studies: 2 ppl.
- Workshop for manufacturing
- Automation development: 2 ppl.
- IT development: 2 ppl.
∴ Execution
- Schneider TSX57303 Premium PLC
- Integrated web communication coupler ‘ETY510)
- 2 Magelis graphic terminals
- Schneider OPC communication server
- Management of 4 axes – TSXCAY42 axis card
- 4 Lexium drives, 6 ATV drives, Parvex drive
- Force measurement by HBM conditioner
- Vision and acquisition by Cognex camera
- Supervision of 24 workstations by PC: proprietary application in VB6
